The Rheon Compact Panner automatically arranges products onto sheet pans produced by the CONUCOPIA system, ensuring high productivity and hygienic operation without manual handling.
Its innovative 3-in-1 design combines a panning conveyor, tray conveyor, and tray feeder into a single compact unit, maximizing space efficiency while streamlining production. Designed to work seamlessly with Rheon single-headed encrusting machines, the Compact Panner delivers consistent product placement while helping maintain product quality and shape throughout the panning process.
Watch our demonstration video!
You are currently viewing a placeholder content from YouTube. To access the actual content, click the button below. Please note that doing so will share data with third-party providers.
More Information
| Tray Size | 740~800 mm (Panning Direction) X 400~600 mm (Tray Flow Direction) X 30 mm |
| Tray Stocker Capacity | up to 16 trays |
| Panning Capacity (MAX.) Continuous | 10 shutters/min. |
| Panning Capacity (MAX.) Intermittent | 60 pcs/min. |
| Length | 1900 mm |
| Width | 1816 mm |
| Height | 1622 mm |
| Wight | 500 kg |
| Belt Width | 75 mm / 130 mm(selectable) |
| Panner Belt Speed | 15.4 m / min. MAX. |
| Electrical Capacity | 0.47 kW |
| Maximum Air Consumption | 0.4 MPa, 10L/min. |
